Technical Parameters ：

Model	LN2226E
Max.Product Size(LxWxH)	220x260x200mm
Steel wire(NumberxdiaxW)	3x140x260
Stripping diameter	0.12-0.3mm
Cutting speed	0.1-999.9mm/h
Wire speed	0-900m/min
Wire storage	20kg
Power	AC380V，50HZ
Total power	<15kw
Dimensions	2620x1520x2300mm
Sand bucket volume	75L / 100L
The thickness of the slice	0.2-5mm
Parallelism of slice	0.02mm
Air/gas consumption	0.2-0.7MPa/400L/min

Features ：

◆ This model is our high speed minicomputer in the current multi-line cutting machine. It is mainly used for batch processing of various hard and brittle materials into the sheet with thickness less than 5mm. It adopts a smaller number of wire wheels and adapts to customers. The processing efficiency, operational stability, process availability and higher economic requirements. The model to ensure high accuracy, high reliability, under the premise of achieving a significant increase in processing efficiency.
◆ machine control system components and bearings, linear guides, ball screws, belts and other mechanical parts are imported high-quality brand-name products.
◆ The key parts of the spindle system are made of high-quality special steel and heat treatment by multi-channel, machining and surface treatment process and then by precision grinding grinding.
◆ Pay-off, take-up, cable, spindle operation, cutting line tension, the table into the use of servo motor drive and control.
◆ mature and comprehensive intelligent control system organically embedded in the accumulation of years of the formation of the perfect process system.
◆ New design, generous, the main operating parts of stainless steel sheet metal structure.
◆ The accuracy of the machine stability, reliability and operation of steel wire speed has reached similar models at home and abroad advanced level, while the machine has a wide range of process applicability.
